How to configure Storage Box Services with OpenStack

OpenStack is a set of software tools for building and managing cloud computing platforms for public and private clouds.It is a cloud operating system that controls large pools of compute, storage, and networking resources throughout a datacenter, all managed through a dashboard.Accessing SAN Storage in OpenStackCinder is the OpenStack component that provides access to, and manages block storage. The cinder interface specifies a number of discrete functions such as create, delete and attach volume/drive etc.Cinder provides persistent block storage resources (volumes) to VMs. These volumes can be detached from one instance and re-attached to another.Cinder supports drivers that allow cinder volumes to be created and presented using storage solutions from vendors. Third-party storage vendors use cinder’s plug-in architecture to do the necessary integration work.Advantages:Driver helps to create LUN and extend the storage capacityDriver helps to back-up the data using backup serviceIt supports both managed/unmanaged LUNIt helps to clone and create volumes from a VM imageMinimum system requirement to configure OpenStack ControllerHardware requirements:Dual-core CPU2 GB RAM5 GB diskSupported OS:RHELCentOSFedoraUbuntuOpenSUSESUSE Linux EnterpriseNetwork:2 Network Interface card with 100 Mbps/1 Gbps speed– One network for OpenStack installation– Another network for storage to make connection with SANNote: OpenStack controller means it includes all the services such as nova, cinder, glance and neutron.SAN Storage:Need one third party storage-subsystem to configure storage with OpenStack.Essential steps to configure SAN storage with OpenStackStep 1Need to setup the following property values in OpenStack cinder configuration file (/etc/cinder/cinder.conf).i. Enable storage backend:enabled_backends = storage name // for example NetAppii. Specify volume name: – to identify particular volume in storagevolume_name_template = openstack-%siii. Add NFS storage information and backup driver: – to backup databackup_driver = cinder.backup.drivers.nfs backup_share =nfs storage IP:/nfsshareiv. Storagebox information[storagename]//For Ex: We should specify NetApp here volume_driver=storage driver volume_backend_name=storage name san_login=storage username san_password=storage password san_ip=storage ipv. Enable multipathuse_multipath_for_image_xfer = TrueNote: StorageBox information and Enable multipath has to be added at the end of configuration file.Step 2Array Vendor’s cinder driver has to be added in below location for creating the volumes in storage/usr/lib/python2.7/site-packages/cinder/volume/drivers/Step 3Restart cinder services:systemctl restart openstack-cinder-api.service systemctl restart openstack-cinder-backup.service systemctl restart openstack-cinder-scheduler.service systemctl restart openstack-cinder-volume.serviceNote: If services are not restarted properties set won’t be effectiveTips and Tricks for trouble shootingSerial 1: Specify network IDSymptom:Error (Conflict): Multiple possible networks found, use a Network ID to be more specific. (HTTP 409) (Request-ID: req-251e6d02-5358-41f7-95a4-b58c52cbc74b). Usually this error occurs only if the given name is ambiguous. It is occurred in OpenStack liberty. Network name is specified while creating the instance. It is failing due to the name given is ambiguous.Approach to tackle the symptom:Affected version: Liberty – Instance is created using network name. Usually this error occurs only if the given name is ambiguous.Fixed version: Mitaka – Instance is created using network id.Issue got fixed in Mitaka which is next release of openstack liberty.To solve the issue, we need specify net id while creating instance.Steps:Login to OpenStack controller node using puttyList all the volume which are created in OpenStack controller node[root@mitaka-hos1~(keystone_admin)]# cinder list +--------------------------------------+-----------+------------------+------+------+--------------+----------+-------------+-------------+ |                  ID                  |   Status  | Migration Status | Name | Size | Volume Type  | Bootable | Multiattach | Attached to | +--------------------------------------+-----------+------------------+------+------+--------------+----------+-------------+-------------+ | eee3f8fc-3306-44c2-84c8-d2ab1ab4c775 | available |     success        | vol2 |  5   | array |   true   |    False    |             | +--------------------------------------+-----------+------------------+------+------+--------------+----------+-------------+-------------+ [root@mitaka-hos1 ~(keystone_admin)]#3. List available networks in OpenStack controller node.[root@mitaka-hos1 ~(keystone_admin)]# neutron net-list +--------------------------------------+---------+------------------------------------------------------+ | id                     | name    | subnets                                              | +--------------------------------------+---------+------------------------------------------------------+ | 489a3170-0ee3-4ae0-a5ef-8a766c50249f | public  | 20ae85c9-a89b-4689-9b76-1c395f842b01 172.24.4.224/28 | | ade84d1d-343c-42ee-a603-df2e84274bd4 | private | ef2e62bc-0b94-44f3-bb2c-82963c2eb705 10.0.0.0/24     | +--------------------------------------+---------+------------------------------------------------------4. Create instance using net-id and volume id.nova boot --flavor m1.tiny --boot-volume eee3f8fc-3306-44c2-84c8-d2ab1ab4c775  --availability-zone     nova:host1  inst3   --nic net-id=489a3170-0ee3-4ae0-a5ef-8a766c50249f +--------------------------------------+--------------------------------------------------+ | Property                             | Value                                            | +--------------------------------------+--------------------------------------------------+ | OS-DCF:diskConfig                    | MANUAL                                           | | OS-EXT-AZ:availability_zone             | nova                                             | ….. ….. | OS-EXT-SRV-ATTR:instance_name        | instance-00000009                                | | OS-EXT-STS:task_state                | scheduling | created                              | 2016-08-31T08:39:20Z                             | | flavor                               | m1.tiny (1)                                      | | hostId                               |                                                  | | id                                   | 8d202079-a9c2-4175-b5ff-7bc0638e06f4             | | image                                | Attempt to boot from volume - no image supplied  | | key_name                             | -                                                | | metadata                             | {}                                               | | name                                 | inst3                                            | | os-extended-volumes:volumes_attached | [{"id": "eee3f8fc-3306-44c2-84c8-d2ab1ab4c775"}] | | progress                             | 0                                                | | security_groups                      | default                                          | | status                               | BUILD                                            | | tenant_id                            | 8c786c64ee8143b4b83bd1109b413ce5                 | | updated                              | 2016-08-31T08:39:21Z                             | | user_id                              | 7aa859512fa146c4ba355d3499fffa14                 | +--------------------------------------+--------------------------------------------------+Bug: https://bugs.launchpad.net/python-novaclient/+bug/1569840Serial 2: Specify multipath in cinder fileSymptom:2016-07-29 04:53:29.728 2103 ERROR cinder.scheduler.manager [req-9de37842-0da5-4c05-9ce3-38b4b38aa1bf 91327080eb604f0596eec6f3191f8b76 322494d5ae904c9680b318e7231bbeff - - -] Failed to schedule_manage_existing: No valid host was found. Cannot place volume 7c1a314a-b46e-475f-8c03-823ba2ca6179 on hostApproach to tackle the symptom:To rectify this issue, need to add below line at end of the cinder.conf.use_multipath_for_image_xfer = TrueSerial 3: Specify pool name in cinder fileSymptom:016-07-20 08:27:44.268 718 ERROR oslo_messaging.rpc.dispatcher     response = self._execute_create_vol(volume, pool_name, reserve) 2016-07-20 08:27:44.268 718 ERROR oslo_messaging.rpc.dispatcher   File "/usr/lib/python2.7/site-packages/cinder/volume/drivers/xxx.py", line 533, in inner_connection_checker 2016-07-20 08:27:44.268 718 ERROR oslo_messaging.rpc.dispatcher     return func(self, *args, **kwargs) 2016-07-20 08:27:44.268 718 ERROR oslo_messaging.rpc.dispatcher   File "/usr/lib/python2.7/site-packages/cinder/volume/drivers/xxx.py", line 522, in inner_response_checker 2016-07-20 08:27:44.268 718 ERROR oslo_messaging.rpc.dispatcher     raise xxxAPIException(msg) 2016-07-20 08:27:44.268 718 ERROR oslo_messaging.rpc.dispatcher xxxAPIException: API _execute_create_vol failed with error string SM-err-pool-not-found 2016-07-20 08:27:44.268 718 ERROR oslo_messaging.rpc.dispatcher Approach to tackle the symptom:Need to specify pool name in end of the cinder.config.ventor_pool_name= pool nameSerial 4: Specify OpenStack controller IPSymptom:Unable to connect to OpenStack instance console using VNC using OpenStack HorizonError Message: Failed to connect to server (code 1006)Environment: OpenStack RDO Juno, CentOS7Approach to tackle the symptom:You need to update vncserver_proxyclient_address with the OpenStack controller IP address OR novavncproxy_base_url IP address in the nova.conf(/etc/nova/nova.conf)vncserver_proxyclient_address=openstack controller IP addressthen restart you compute service/etc/init.d/openstack-nova-compute restartSerial 5: Specify nfs driver in cinder configSymptom:[root@hiqa-rhel1 ~(keystone_admin)]# cat /var/log/cinder/backup.log | grep unsupport 2017-02-10 04:21:17.143 22496 DEBUG cinder.service [req-5210ae1c-ae31-41e5-b927-9102c776e941 - - - - -] enable_unsupported_driver : False wait /usr/lib/python2.7/site-packages/cinder/service.py:611 2017-02-10 04:21:17.222 22496 DEBUG oslo_service.service [req-5210ae1c-ae31-41e5-b927-9102c776e941 - - - - -] enable_unsupported_driver      = False log_opt_values /usr/lib/python2.7/site-packages/oslo_config/cfg.py:2622 2017-02-10 04:34:43.918 27333 DEBUG cinder.service [req-95201c9a-8766-4589-b4be-3d076890fc54 - - - - -] enable_unsupported_driver : False wait /usr/lib/python2.7/site-packages/cinder/service.py:611 2017-02-10 04:34:43.977 27333 DEBUG oslo_service.service [req-95201c9a-8766-4589-b4be-3d076890fc54 - - - - -] enable_unsupported_driver      = False log_opt_values /usr/lib/python2.7/site-packages/oslo_config/cfg.py:2622 2017-02-11 22:17:41.654 17423 DEBUG cinder.service [req-9b064618-21cd-4400-a428-70b909c3d141 - - - - -] enable_unsupported_driver : False wait /usr/lib/python2.7/site-packages/cinder/service.py:611 2017-02-11 22:17:41.709 17423 DEBUG oslo_service.service [req-9b064618-21cd-4400-a428-70b909c3d141 - - - - -] enable_unsupported_driver      = False log_opt_values /usr/lib/python2.7/site-packages/oslo_config/cfg.py:2622 [root@hiqa-rhel1 ~(keystone_admin)]# Approach to tackle the symptom:To rectify this issue, need to specify nfs driver in the cinder.conf file:backup_driver = cinder.backup.drivers.nfsSerial 6: Grant permission to backup volume in nfs serverSymptom:OSError: [Errno 13] Permission denied: '/var/lib/cinder/backup_mount/f Approach to tackle the symptom:chown cinder:cinder -R /var/lib/cinder/backup_mount/
